Automatic Polymer Foaming Machine

Our company specializes in providing three-tank polymer automatic dosing machines. The product features are as follows:

The polymer automatic dosing machine is equipped with a full stainless-steel housing and fully imported components.
The polymer automatic dosing machine operates fully automatically, saving labor costs.
The polymer automatic dosing machine has an elegant appearance and is easy to maintain.

Get in Touch

Share To:

Home / Products / Dosing Mahcine / Automatic Polymer Foaming Machine

Application

• Coagulation aid in municipal wastewater

• Sludge treatment and sedimentation

• Coagulation aid in industrial wastewater

• Lime dosing

Key Features

Saving labor costs

Fully automatic operation, saving labor costs

Precisely adjustable

Precisely adjustable dosing volume to ensure treatment effectiveness and avoid waste

Excellent corrosion resistance

Full stainless-steel housing with fully imported components, ensuring reliable quality, excellent corrosion resistance, easy maintenance, and elegant appearance

Customizable

Strong technical support, with the dosing machine customizable to meet user-specific process requirements

Parameter Information

JDP 500-8000 Specifications and Dimensions
Model	Constructive style	Liquid Preparati (Lt/hr)	Powder supply tank capacity	Powder conveyor(speed fixed)	Fluid mixer(speed fixed)	Tanks body material		Machine dimensions (mm)					Weight(Kgs)
Model	Constructive style	Liquid Preparati (Lt/hr)	Powder supply tank capacity	Powder conveyor(speed fixed)	Fluid mixer(speed fixed)	Standard	Special asigment	L	W	H	L1	W1	Weight(Kgs)
JDP500	3 tanks conti-nuous type	500	55	1/4	1/4*3	SUS304 Stainless Steel	SUS316 stainless steel)or PP. PVC.FRP.	1750	850	1700	1290	640	280
JDP-1000		1000	55	1/4	1/4*3			2050	950	2000	1480	740	410
JDP-1500		1500	55	1/4	1/2*3			2300	1100	2000	1650	900	490
JDP 2000		2000	110	1/4	1/2*3			2650	1250	2250	2010	1030	550
JDP 3000		3000	110	1/4	1*3			3150	350	2300	2470	1120	680
JDP-5000		5000	200	1/4	2*3			3250	1650	2600	2500	1430	960
JDP-8000		8000	350	1/4	2*3			4750	1850	2900	3970	1630	1280
Note: The above parameters are for reference only. Please refer to the final order specification.

Frequently Asked Questions

Our popular products include: vehicle-mounted sludge solidification units, diaphragm filter presses, sludge dewatering machines, as well as engineering design and installation services for municipal sludge and sand-washing sludge treatment.

How to choose the right filter press model based on material properties?

Selecting a filter press model depends on key material properties: particle size (to determine filter cloth mesh), viscosity (affects required pressure), corrosiveness (dictates filter plate material, e.g., PP for mild corrosion, stainless steel for strong), and solid content (influences filtration area and cycle time). High-solids materials need larger filtration areas, while abrasive materials require wear-resistant plates. Match pressure ratings to material viscosity—thicker slurries need higher pressure (1.0–2.5 MPa) for effective dewatering.

What to do if filter plates leak?

First, stop operation and check:

Filter cloths: Replace damaged or misaligned cloths that disrupt sealing.
Filter plate seals: Inspect for cracks, wear, or debris; clean seals or replace plates if damaged.
Pressure imbalance: Ensure uniform pressure across plates (adjust hydraulic system if uneven).
Plate alignment: Realign plates if shifted during operation. Test with low pressure after fixes to confirm leaks are resolved.

Do filter cloths need regular replacement? How often?

Yes, filter cloths require regular replacement as they clog, tear, or degrade over time, reducing filtration efficiency. Frequency depends on material: 4–8 weeks for abrasive/viscous materials (e.g., mining slurries); 3–6 months for less harsh materials (e.g., food-grade liquids). Signs to replace early: slower filtration, increased pressure, or visible damage (holes, fraying).

Is installation and operation training provided after purchase?

We offer installation and operation training post-purchase. This typically includes on-site installation guidance, hands-on operation training (e.g., setting parameters, troubleshooting), and documentation (manuals, video tutorials). Some provide follow-up support for 1–3 months to ensure operators master key functions, especially for automated or custom models.

If the power supply is not the issue, how to fix the machine tripping and shutting down?

Check these common causes:

Overload: Motor may be overworked (e.g., excessive slurry feed); reduce load or inspect for jammed components (e.g., filter plate movement).
Faulty sensors: Pressure or temperature sensors may trigger safety shutdowns; calibrate or replace malfunctioning sensors.
Hydraulic system issues: Low oil level or clogged filters can cause pressure spikes; check fluid levels and clean/replace filters.
Electrical connections: Loose wires in control panels may interrupt power; tighten connections and inspect for short circuits.
