ZJE Series Filter Press Feed Pump

The ZJE series filter press feed pump is a specially designed slurry pump developed based on fluid dynamics principles. It utilizes a dual impeller design with opposite rotation, and a compact mechanical seal to prevent leakage.

Get in Touch

Share To:

Home / Products / Pump for Filter Press / ZJE Series Filter Press Feed Pump

Introduction

The ZJE series filter press feed pump is a specially designed slurry pump developed based on fluid dynamics principles. It utilizes a dual impeller design with opposite rotation, and a compact mechanical seal to prevent leakage. During operation, the pump utilizes the pressure changes within the filter press to achieve high initial flow rate and low pressure, reducing impact on the filter plate frame and extending filter cloth lifespan. The low flow rate in later stages prevents pump stalling and filter press clogging, reducing energy consumption and eliminating the need for speed control during filter press operation.

Advantages & Applications

Advantages

This equipment uses an energy-efficient motor to reduce energy consumption. It features high-strength mechanical seals and robust bearings, ensuring stability and reliability during high-speed operation.

Applications

Chemical industry, mining industry, wastewater treatment industry, food industry, etc.

Parameter Information

Model	Rotational Speed	Flow	Lift head	Main shaft power	Motor		Caliber	Transmission
	n	Q	H	pa	Model	Power/Voltage kw/v	Entrance / Exit mm/mm
	r/min	m3	m	kw
50ZJE-310	1450	20	65	13	Y160L-4	15KW/380	65/80	DC
		30	40
50ZJE-330	1450	30	75	18.5	Y180L-4	22KW/380	65/80	DC
		50	50
65ZJE-340	148D	50	80	26.5	Y2D0L-4	30KW/380	100/10D	DC
		70	55
65ZJE-34D	148D	55	80	33	Y225M-4	37KW/380	100/10D	DC
		100	58
65ZJE-34D	148D	62	80	40	Y225M-4	45KW/380	100/100	DC
		120	60
B0ZJE-34D	148D	76	80	49	Y2505-4	55KW/380	100/15D	DC
		169	62
10DZJE-340	148D	83	80	69	Y28DM-4	75KW/380	100/15D	DC
		198	62
10DZJE-360	148D	98	80	80	Y28DM-4	90KW/380	100/15D	DC
		279	65
50ZJE-23D	290D	15 18 29	12D 116 110	16	Y180L-2	22KW/380	50/65	DC
65ZJE-24D	290D	25 35 45	13D 125 118	26	Y2D0L-2	30KW/380	65/80	DC
50ZJE-200	2900	15	62	5.5	Y132M-2	75KW/380	65/80	DC
		22	40
50ZJE-200	2900	25	62	11	Y160M-2	15KW/380	65/80	DC
		40	40
50ZJE-210	2900	15	62	5	Y132M-2	75KW/380	50/65	DC
		20	40
50ZJE-210	2900	25	62	11	Y160M-2	15KW/380	65/65	DC
		40	40
65ZJE-230	2900	37	68	15	Y160M-2	18.5KW/380	65/80	DC
		50	42
65ZJE-230	2900	40	68	18	Y180M-2	22KW/380	65/80	DC
		60	42
65ZJE-250	2900	50	80	30	Y200L-2	37KW/380	65/80	DC
		70	55
80ZJE-420	1480	90	70	39	Y225M-4	45KW/380	80/125	DC
		150	55
80ZJE-420	1480	95	70	47	Y250M-4	55KW/380	80/125	DC
		170	55
100ZJE-420	1480	70	70	32	Y225M-4	37KW/380	100/150	DC
		130	55
100ZJE-420	1480	110	70	63	Y2805-4	75KW/380	100/150	DC
		220	55

Frequently Asked Questions

Our popular products include: vehicle-mounted sludge solidification units, diaphragm filter presses, sludge dewatering machines, as well as engineering design and installation services for municipal sludge and sand-washing sludge treatment.

How to choose the right filter press model based on material properties?

Selecting a filter press model depends on key material properties: particle size (to determine filter cloth mesh), viscosity (affects required pressure), corrosiveness (dictates filter plate material, e.g., PP for mild corrosion, stainless steel for strong), and solid content (influences filtration area and cycle time). High-solids materials need larger filtration areas, while abrasive materials require wear-resistant plates. Match pressure ratings to material viscosity—thicker slurries need higher pressure (1.0–2.5 MPa) for effective dewatering.

What to do if filter plates leak?

First, stop operation and check:

Filter cloths: Replace damaged or misaligned cloths that disrupt sealing.
Filter plate seals: Inspect for cracks, wear, or debris; clean seals or replace plates if damaged.
Pressure imbalance: Ensure uniform pressure across plates (adjust hydraulic system if uneven).
Plate alignment: Realign plates if shifted during operation. Test with low pressure after fixes to confirm leaks are resolved.

Do filter cloths need regular replacement? How often?

Yes, filter cloths require regular replacement as they clog, tear, or degrade over time, reducing filtration efficiency. Frequency depends on material: 4–8 weeks for abrasive/viscous materials (e.g., mining slurries); 3–6 months for less harsh materials (e.g., food-grade liquids). Signs to replace early: slower filtration, increased pressure, or visible damage (holes, fraying).

Is installation and operation training provided after purchase?

We offer installation and operation training post-purchase. This typically includes on-site installation guidance, hands-on operation training (e.g., setting parameters, troubleshooting), and documentation (manuals, video tutorials). Some provide follow-up support for 1–3 months to ensure operators master key functions, especially for automated or custom models.

If the power supply is not the issue, how to fix the machine tripping and shutting down?

Check these common causes:

Overload: Motor may be overworked (e.g., excessive slurry feed); reduce load or inspect for jammed components (e.g., filter plate movement).
Faulty sensors: Pressure or temperature sensors may trigger safety shutdowns; calibrate or replace malfunctioning sensors.
Hydraulic system issues: Low oil level or clogged filters can cause pressure spikes; check fluid levels and clean/replace filters.
Electrical connections: Loose wires in control panels may interrupt power; tighten connections and inspect for short circuits.
